• Enables Taller Gravity Walls: They increase the depth and mass of the wall's base in 2 ft. or 4 ft. increments, which significantly enhances stability..

• Minimizes Excavation and Maximizes Space: By replacing traditional geogrid reinforcement in many applications, they drastically reduce the required excavation area (sometimes as low as a 40% base-to-height ratio compared to 70% for geogrid designs). This maximizes usable land above and in front of the wall and allows construction closer to property lines.

• Simplifies Installation and Access: The concrete tongue-and-groove system is simple to install, reducing labor and equipment costs. Without layers of geogrid, it also provides easier installation and access to utilities, pipes, and drainage systems located behind the wall for maintenance.

• Increased Flexibility and Strength: The extenders, available in multiple lengths, can be overlapped to provide additional strength and flexibility, especially for complex sections like outside corners

• Reduced Labor Costs: A large block that covers 8 sq. ft. of wall face per unit means fewer blocks need to be handled, significantly speeding up the process. Some 2 to 3 person crews can install over 1,000 sq. ft. per day.

• Shorter Project Timelines: The speed means the project is completed faster, reducing overall site time, labor hours, and disruption.

• Lower Equipment Costs: The hollow-core design makes the blocks up to 40% lighter than solid concrete systems. This allows contractors to use smaller, more affordable equipment (like a standard Bobcat that can lift two blocks at once), instead of larger, more expensive excavators.

The MagnumStone Design and Analysis Software is a comprehensive tool specifically created for retaining wall engineers. Its core purpose is to provide a detailed, site-specific, and structurally sound design, moving the project from concept to construction-ready plans efficiently.

The program allows engineers to input and calculate for complex site conditions to ensure wall stability:

• Site-Specific Inputs: Users can customize and edit detailed information for soil compositions (reinforced, retained, and foundation soils), slopes (above and below the wall), and water analysis (internal and external drainage).

• Load Calculations: It accurately factors in various loads, including live loads (like traffic or parking lots) and dead loads (like structures or existing fill).

• Stability Checks: It performs rigorous analysis, including External Stability (sliding, overturning, bearing capacity) and Internal Stability (geogrid strength/pullout).

• Global Stability & Seismic: It includes features to perform global stability analysis and input seismic factors (peak acceleration) for regions prone to earthquakes.​

The program is designed to deliver construction-ready documents quickly:

• Accurate Quantity Takeoffs: Generates precise lists for all required materials, including the exact number of blocks, extenders, and the specific lengths and layers of geogrid needed for quoting (as discussed previously).

• Export Functionality: Designs can be easily exported to AutoCAD, allowing the engineer to integrate the wall plan directly into the overall site plan and construction drawings.

• Detailed Reports: Provides comprehensive reports containing all design calculations, cross-sections, and material summaries for submission to the engineer of record or regulatory bodies.
